3.5 Use of a 102/105-Key Keyboard with the Compact Panel
A standard 102/105-key PC keyboard can be connected to the front of the compact panel (see 3.1.1.4) after removing
the dust cap (or to the rear if the DIN connector was moved to the rear of the panel), for instance to enter or edit part
programmes.
This keyboard should also be used for accessing the utilities. Press Ctrl + S to exit from the utilities.
!
CAUTION
A keyboard should only be connected exceptionally to the front panel, because removal of
the dust cap breaks the panel seal. Move the connector to the rear of the panel if the
keyboard is to remain permanently connected.
Three types of standard 102/105-key PC keyboards can be connected
AZERTY French keyboard
Specify the use of an AZERTY keyboard on the keyboard. ☞
Arrêt
Défil
+
1
The configuration with AZERTY keyboard is saved in the system memory.
QWERTY English keyboard
Specify the use of a QWERTY keyboard on the keyboard. ☞
Scroll
Lock
+
0
The configuration with QWERTY keyboard is saved in the system memory.
QWERTZ German keyboard
Specify the use of a QWERTZ keyboard on the keyboard. ☞
Scroll
Lock
+
2
The configuration with QWERTZ keyboard is saved in the system memory.
!
CAUTION
The PC keyboard must have the following characteristics:
- Standard keyboard with 102 or 105 keys (excluding Compaq),
- Maximum power consumption: 150 mA,
- 5-contact DIN connector.
