NUM 1040 W User Manual

3 - 6 en-938821/2
3.1.2 Display Screen
2
1
3
5
4
1 - Status window
2 - Main window (20 lines of small characters)
3 - Modal data window
4 - Dialogue window (3 dialogue lines)
5 - Softkey bar
Certain screens do not have a dialogue window. In this case, 11 lines of large characters are displayed.
