Nvidia ConnectX-6 Dx User Manual

5
About This Manual
This is the User Guide for Ethernet NVIDIA® ConnectX®-6 Dx adapter cards for Open Compute
Project Spec 3.0. These adapters' connectivity provides the highest performing low latency and most
flexible interconnect solution for servers supporting OCP spec 3.0 adapter cards used in Enterprise
Data Centers and High-Performance Computing environments.
Important Note:
In some of the OCP 3.0 prototype samples, the insertion force that is required to install the card
into a particular PCI connector may exceed the maximum insertion force that is allowed by the
connector’s spec. NVIDIA is updating the OCP 3.0 cards to ensure the proper insertion process.
Ordering Part Numbers
The table below provides the ordering part numbers (OPN) for the available ConnectX-6 Dx Ethernet
adapter cards for OCP Spec 3.0.
NVIDIA SKU OPN Marketing Description
900-9X624-0073-SB0 MCX623432AS-ADAB ConnectX®-6 Dx EN adapter card,
25GbE, OCP3.0, With Host management,
Dual-port SFP28, PCIe 4.0 x16,Secure
Boot, No Crypto,Thumbscrew (Pull Tab)
Bracket
900-9X624-0085-SB0 MCX623432AC-GDAB ConnectX®-6 Dx EN adapter card,
50GbE, OCP3.0, With Host Management,
Dual-port SFP56, PCIe 4.0 x16, Crypto
and Secure Boot, Thumbscrew (Pull Tab)
Bracket
900-9X658-0016-SB0
MCX623435AN-CDAB
ConnectX®-6 Dx EN adapter card,
100GbE, OCP3.0, With Host
management, Single-port QSFP56, PCIe
4.0 x16, No Crypto, Thumbscrew (Pull
Tab) Bracket
900-9X658-0046-SB0 MCX623435AC-CDAB ConnectX-6 Dx EN adapter card,
100GbE, OCP3.0, With Host
Management, Single-portQSFP56, PCIe
4.0 x16, Crypto and Secure Boot,
Thumbscrew (Pull Tab) Bracket
900-9X658-0056-MB0
MCX623436MN-CDAB ConnectX®-6 Dx EN adapter card,
100GbE, OCP3.0, With Host
management, Dual-port QSFP56, Multi-
Host or Socket Direct, PCIe 4.0 x16, No
Crypto, Thumbscrew (Pull Tab) Bracket
900-9X658-0076-MB0
MCX623436MS-CDAB ConnectX®-6 Dx EN adapter card,
100GbE, OCP3.0, With Host
management, Dual-port QSFP56, Multi-
Host or Socket Direct, PCIe 4.0 x16,
Secure Boot, No Crypto, Thumbscrew
(Pull Tab) Bracket
900-9X675-0076-MB0 MCX623430MS-CDAB
ConnectX-6 Dx EN adapter card, 100GbE
OCP3.0, With Host Management,
Dual-port DSFP, Multi-Host or Socket
Direct, PCIe 4.0 x16, Secure Boot, No
Crypto, Thumbscrew (Pull Tab) Bracket
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Nvidia ConnectX-6 Dx Specifications

General

Product Name	Nvidia ConnectX-6 Dx
Category	Adapter
Network Interface	Ethernet, InfiniBand
Port Speed	200Gb/s
Form Factor	Low Profile
PCIe Interface	PCIe 4.0 x16
Operating Temperature	0°C to 55°C
Product Type	Network Adapter
InfiniBand Support	Yes
RoHS Compliance	Yes
Virtualization Support	SR-IOV
Data Link Protocol	Ethernet, InfiniBand
Ports	2
Ethernet Standards	IEEE 802.3
Security Features	IPsec, TLS
