Nvidia ConnectX-6 Dx User Manual

57
Specifications
MCX623432AE-ADAB / MCX623432AN-ADAB /
MCX623432AC-ADAB /MCX623432AS-ADAB Specifications
Physical
Form Factor: Small Form Factor (SFF) OCP 3.0
Size: 4.52 in. x 2.99 in (115.00mm x 76.00mm)
Connector: Dual SFP28 Ethernet (copper and optical)
Retention Mechanism: Thumbscrew(Pull Tab) Bracket
Protocol Support
Ethernet: 25GBASE-R, 20GBASE-KR2, 10GBASE-LR, 10GBASE-ER, 10GBASE-CX4, 10GBASE-
KX4, 10GBASE-CR, 10GBASE-KR, SGMII, 1000BASE-CX, 1000BASE-KX, 10GBASE-SR
Data Rate: Ethernet 1/10/25 Gb/s
PCI Express Gen 4.0: SERDES @ 16.0GT/s, 16 lanes (2.0 and 1.1 compatible)
Power and
Airflow
Voltage: 3.3VAUX, 12V
Cable Type Active Mode Standby Mode
Typical Power
(b)
Passive Cables 15.7W 3.8W
Maximum Power Passive Cables 19.74W 7.95W
Maximum power available through SFP28 port:1.5W
Airflow Cable Type Hot Aisle
HSK to Port
Cold Aisle @35C
Port to HSK
Passive Cable Active
Mode
@55C
Standby
Mode
@45C
Active
Mode
Standby
Mode
400LFM 400LFM TBD TBD
Environmental
Temperature Operational 0°C to 55°C
Non-operational -40°C to 70°C
Humidity Operational 10% to 85% relative humidity
Non-operational 10% to 90% relative humidity
Altitude (Operational) 3050m
Regulatory
Safety
CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
Install the ConnectX-6 Dx OCP 3.0 card in a PCIe slot that is capable of supplying the power
levels mentioned below for the appropriate use case

In Standby mode only port0 is available.

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Nvidia ConnectX-6 Dx Specifications

General

Product Name	Nvidia ConnectX-6 Dx
Category	Adapter
Network Interface	Ethernet, InfiniBand
Port Speed	200Gb/s
Form Factor	Low Profile
PCIe Interface	PCIe 4.0 x16
Operating Temperature	0°C to 55°C
Product Type	Network Adapter
InfiniBand Support	Yes
RoHS Compliance	Yes
Virtualization Support	SR-IOV
Data Link Protocol	Ethernet, InfiniBand
Ports	2
Ethernet Standards	IEEE 802.3
Security Features	IPsec, TLS
