Nvidia ConnectX-6 Dx User Manual

59
a.ConnectX-6 Dx adapters supplement the auto-negotiation specification to get better bit error
rates and longer cable reaches. This supplemental feature only initiates when connected to another
NVIDIA Ethernetproduct.
b. Typical power for ATIS traffic load.
c. For both operational and non-operational states.
MCX623435MN-CDABSpecifications
Physical
Form Factor: Small Form Factor (SFF) OCP 3.0
Size: 4.52 in. x 2.99 in (115.00mm x 76.00mm)
Connector: Single QSFP56 Ethernet (copper and optical)
Retention Mechanism: Thumbscrew(Pull Tab) Bracket
Protocol
Support
Ethernet: 100GBASE-CR4, 100GBASE-KR4, 100GBASE-SR4,100GBASE-CR2, 100GBASE-KR2,
100GBASE-SR2, 50GBASE-R2, 50GBASE-R4, 40GBASE-CR4, 40GBASE-KR4, 40GBASE-SR4,
40GBASE-LR4, 40GBASE-ER4, 40GBASE-R2, 25GBASE-R, 20GBASE-KR2, 10GBASE-LR,10GBASE-
ER, 10GBASE-CX4, 10GBASE-CR, 10GBASE-KR, SGMII, 1000BASE-CX, 1000BASE-KX, 10GBASE-SR
Data Rate: Ethernet 1/10/25/40/50/100 Gb/s
PCI Express Gen 4.0: SERDES @ 16.0GT/s, 16 lanes (2.0 and 1.1 compatible)
Power and
Airflow
Voltage: 3.3VAUX, 12V
Power Cable Type Active Mode Standby Mode
Typical Power
(b)
Passive Cables 18W 5.7W
Maximum Power Passive Cables 23.4W 10W
Maximum power available through QSFP56 port:5W
Airflow
Cable Type Hot Aisle
HSK to Port
Cold Aisle @35C
Port to HSK
Active Mode
@55C
Standby
Mode@5
0C
Active Mode Standby Mode
Passive Cable
500LFM
100LFM 300LFM
100LFM
Environment
al
Temperature Operational 0°C to 55°C
Non-
operational
-40°C to 70°C
Humidity Operational 10% to 85% relative humidity
Non-
operational
10% to 90% relative humidity
Altitude
(Operational)
3050m
Regulatory
Safety
CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
