Monitoring
Thermal Sensors
The adapter card incorporates the ConnectX IC, which operates in the range of temperatures
between 0°C and 105°C.
Three thermal threshold definitions impact the overall system operation state:
Warning– 105°C: On managed systems only: When the device crosses the 105°C threshold, a
Warning Threshold message is issued by the management SW, indicating to system
administration that the card has crossed the warning threshold. Note that this temperature
threshold does not require nor lead to any action by hardware (such as adapter card
shutdown).
Critical– 115°C: When the device crosses this temperature, the firmware automatically shuts
down the device.
Emergency– 130°C: If the firmware fails to shut down the device upon crossing the critical
threshold, the device automatically shuts down upon crossing the emergency (130°C)
threshold.
The card's thermal sensors can be read through the system’s SMBus. The user can read these
thermal sensors and adapt the system airflow following the readouts and the needs of the above-
mentioned IC thermal requirements.
Adapter Card Heatsink
A heatsink is attached to the ConnectX-6 Dx IC to dissipate the heat. It is connected by four spring-
loaded push pins that insert into four mounting holes.
ConnectX®-6 Dx IC has a thermal shutdown safety mechanism that automatically shuts down the
ConnectX®-6 Dx card in case of a high-temperature event, improper thermal coupling, or heatsink
removal.
For the required airflow (LFM) per OPN, please refer to theSpecificationschapter.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Nvidia ConnectX-6 Dx Specifications

General

Product Name	Nvidia ConnectX-6 Dx
Category	Adapter
Network Interface	Ethernet, InfiniBand
Port Speed	200Gb/s
Form Factor	Low Profile
PCIe Interface	PCIe 4.0 x16
Operating Temperature	0°C to 55°C
Product Type	Network Adapter
InfiniBand Support	Yes
RoHS Compliance	Yes
Virtualization Support	SR-IOV
Data Link Protocol	Ethernet, InfiniBand
Ports	2
Ethernet Standards	IEEE 802.3
Security Features	IPsec, TLS
