Nvidia ConnectX-6 Dx User Manual

62
Altitude
(Operational)
3050m
Regulatory
Safety
CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
a.ConnectX-6 Dx adapters supplement theauto-negotiation specification to get better bit error
rates and longer cable reaches. This supplemental feature only initiates when connected to another
NVIDIA Ethernetproduct.
b. Typical power for ATIS traffic load.
c. For both operational and non-operational states.
MCX623430MS-CDAB Specifications
Physical
Form Factor: Small Form Factor (SFF) OCP 3.0
Size: 4.52 in. x 2.99 in (115.00mm x 76.00mm)
Connector: Dual DSFP Ethernet (copper and optical)
Retention
Mechanism:
Thumbscrew (Pull Tab) Bracket
Protocol
Support
Ethernet: 100GBASE-CR4, 100GBASE-KR4, 100GBASE-SR4, 100GBASE-CR2,
100GBASE-KR2, 100GBASE-SR2, 50GBASE-R2, 50GBASE-R4, 40GBASE-CR4,
40GBASE-KR4, 40GBASE-SR4, 40GBASE-LR4, 40GBASE-ER4, 40GBASE-R2, 25GBASE-
R, 20GBASE-KR2, 10GBASE-LR,10GBASE-ER, 10GBASE-CX4, 10GBASE-CR, 10GBASE-
KR, SGMII, 1000BASE-CX, 1000BASE-KX, 10GBASE-SR
Data Rate: Ethernet 1/10/25/40/50/100 Gb/s
PCI Express Gen 4.0: SERDES @ 16.0GT/s, 16 lanes (2.0 and 1.1 compatible)
Power and
Airflow
Voltage: 3.3VAUX, 12V
Power Cable Type Active Mode Standby Mode
Typical Power
(b)
Passive Cables 19W 5.7W
Maximum Power Passive Cables 26.6W 10W
Maximum power available through DSFP port:5W
Airflow
Cable Type Hot Aisle
HSK to Port
Cold Aisle @35C
Port to HSK
Normal
Mode
@55C
Standby
Mode
@45C
Normal
Mode
Standby
Mode
Passive Cable 600LFM 100LFM 300LFM 100LFM
Environmental
Temperature Operational 0°C to 55°C
Non-
operational
-40°C to 70°C
Humidity Operational 10% to 85% relative humidity
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Nvidia ConnectX-6 Dx Specifications

General

Product Name	Nvidia ConnectX-6 Dx
Category	Adapter
Network Interface	Ethernet, InfiniBand
Port Speed	200Gb/s
Form Factor	Low Profile
PCIe Interface	PCIe 4.0 x16
Operating Temperature	0°C to 55°C
Product Type	Network Adapter
InfiniBand Support	Yes
RoHS Compliance	Yes
Virtualization Support	SR-IOV
Data Link Protocol	Ethernet, InfiniBand
Ports	2
Ethernet Standards	IEEE 802.3
Security Features	IPsec, TLS
