Nvidia ConnectX-6 Dx User Manual

9
Introduction
This is the User Guide for Ethernet adapter cards based on the ConnectX®-6 Dx integrated circuit
device for OCP Spec 3.0. These adapters connectivity provide the highest performing low latency
and most flexible interconnect solution for servers supporting OCP 3.0used in Enterprise Data
Centers and High-Performance Computing environments.
Important Note:
In some of the OCP 3.0 prototype samples, the insertion force that is required to install the card
into a particular PCI connector may exceed the maximum insertion force that is allowed by the
connector’s spec.NVIDIA is updating the OCP 3.0 cards to ensure the proper insertion process.
The following table provides the ordering part number, port speed, number of ports, and PCI Express
speed.
Products Overview
ConnectX-6 Dx 25GbE Adapter Cards for OCP 3.0
OPN MCX623432AN-
ADAB
MCX623432AC-
ADAB
MCX623432AE-
ADAB
MCX623432AS-
ADAB
Network Connector
Type
Dual-port SFP28
Dual-port SFP28 Dual-port SFP28 Dual-port SFP28
Ethernet Data Rate 10/25 Gb/s
PCI Express
Connectors
PCIe Gen 3.0 / 4.0 x16
SERDES @ 8.0GT/s / 16.0GT/s
Dimensions
Small Form Factor (SFF) OCP 3.0
4.52 in. x 2.99 in (115.00mm x 76.00mm)
Retention Mechanism Thumbscrew(Pull Tab) Bracket
RoHS RoHS Compliant RoHS Compliant RoHS Compliant RoHS Compliant
IC Part Number MT28928A0-XCCF-CE MT28928A0-XCCF-
CE
MT28928A0-XCCF-CE
MT28928A0-XCCF-CE
Host Management ✔ ✔ ✔ ✔
Crypto - ✔ ✔ -
Secure Boot ✔ ✔ - ✔
Device ID
4125 for Physical Function (PF)
4126 for Virtual Function (VF)
ConnectX-6 Dx 50GbE Adapter Cards for OCP 3.0
OPN MCX623432AN-GDAB MCX623432AC-GDAB MCX623432AS-GDAI
Network Connector Type Dual-port SFP56 Dual-port SFP56 Dual-port SFP56
Ethernet Data Rate 10/25/50 Gb/s
Please note the following OPNs are shipped with an assembled thumbscrew(pull tab)
bracket. For other retention mechanism brackets, please contact NVIDIA.

Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Nvidia ConnectX-6 Dx Specifications

General

Product Name	Nvidia ConnectX-6 Dx
Category	Adapter
Network Interface	Ethernet, InfiniBand
Port Speed	200Gb/s
Form Factor	Low Profile
PCIe Interface	PCIe 4.0 x16
Operating Temperature	0°C to 55°C
Product Type	Network Adapter
InfiniBand Support	Yes
RoHS Compliance	Yes
Virtualization Support	SR-IOV
Data Link Protocol	Ethernet, InfiniBand
Ports	2
Ethernet Standards	IEEE 802.3
Security Features	IPsec, TLS
