Nvidia ConnectX-6 Dx User Manual

58
a.ConnectX-6 Dx adapters supplement theauto-negotiation specification to get better bit error
rates and longer cable reaches. This supplemental feature only initiates when connected to another
NVIDIA Ethernetproduct.
b. Typical power for ATIS traffic load.
c. For both operational and non-operational states.
MCX623432AC-GDAB / MCX623432AN-GDAB /
MCX623432AS-GDAISpecifications
Physical
Form Factor: Small Form Factor (SFF) OCP 3.0
Size: 4.52 in. x 2.99 in (115.00mm x 76.00mm)
Connector: Dual SFP56 Ethernet (copper and optical)
Retention Mechanism:
MCX623432A[N/C]-GDAB: Thumbscrew(Pull Tab) Bracket
MCX623432AS-GDAI: Internal Lock
Protocol
Support
Ethernet: 50GBASE-R2, 50GBASE-R4, 40GBASE-CR4, 40GBASE-KR4, 40GBASE-SR4, 40GBASE-LR4,
40GBASE-ER4, 40GBASE-R2, 25GBASE-R, 20GBASE-KR2, 10GBASE-LR,10GBASE-ER, 10GBASE-CX4,
10GBASE-CR, 10GBASE-KR, SGMII, 1000BASE-CX, 1000BASE-KX, 10GBASE-SR
Data Rate Ethernet 1/10/25/40/50 Gb/s
PCI Express Gen 4.0: SERDES @ 16.0GT/s, 16 lanes (2.0 and 1.1 compatible)
Power and
Airflow
Voltage: 3.3VAUX, 12V
Power Cable Type Active Mode Standby Mode
Typical Power
(b)
Passive Cables 16.9W 4.54W
Maximum Power Passive Cables 21.4W 8.75W
Maximum power available through SFP56 port:2W
Airflow Cable Type Hot Aisle
HSK to Port
Cold
Aisle@35C
Port to HSK
Active
Mode
@55C
Standby
Mode
@45C
Active
Mode
Standby
Mode
Passive Cable 400LFM 100LFM TBD TBD
Environme
ntal
Temperature Operational 0°C to 55°C
Non-operational -40°C to 70°C
Humidity Operational 10% to 85% relative humidity
Non-operational 10% to 90% relative humidity
Altitude (Operational) 3050m
Regulatory
Safety
CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Nvidia ConnectX-6 Dx Specifications

General

Product Name	Nvidia ConnectX-6 Dx
Category	Adapter
Network Interface	Ethernet, InfiniBand
Port Speed	200Gb/s
Form Factor	Low Profile
PCIe Interface	PCIe 4.0 x16
Operating Temperature	0°C to 55°C
Product Type	Network Adapter
InfiniBand Support	Yes
RoHS Compliance	Yes
Virtualization Support	SR-IOV
Data Link Protocol	Ethernet, InfiniBand
Ports	2
Ethernet Standards	IEEE 802.3
Security Features	IPsec, TLS
