Nvidia ConnectX-6 Dx User Manual

7
•
•
NVIDIA SKU OPN Marketing Description
900-9X624-0083-SB0
MCX623432AC-ADAB ConnectX®-6 Dx EN adapter card, 25GbE, OCP3.0,
With Host Management, Dual-port SFP28, PCIe 4.0
x16, Crypto and Secure Boot, Thumbscrew (Pull
Tab) Bracket
900-9X624-0003-SB0
MCX623432AN-ADAB ConnectX®-6 Dx EN adapter card, 25GbE, OCP3.0,
With Host management, Dual-port SFP28, PCIe 4.0
x16, No Crypto, Thumbscrew (Pull Tab) Bracket
900-9X624-0055-SB0
MCX623432AN-GDAB ConnectX®-6 Dx EN adapter card, 50GbE, OCP3.0,
With Host Management, Dual-port SFP56, PCIe 4.0
x16, No Crypto, Thumbscrew (Pull Tab) Bracket
900-9X658-0048-SB0 MCX623435AC-VDAB
ConnectX®-6 Dx EN adapter card, 200GbE,
OCP3.0, With Host Management, Single-port
QSFP56, PCIe 4.0 x16, Crypto and Secure Boot,
Thumbscrew (Pull Tab) Bracket
900-9X658-0016-MB0
MCX623435MN-CDAB ConnectX®-6 Dx EN adapter card, 100GbE,
OCP3.0, With Host Management, Single-port
QSFP56, Multi-Host or Socket Direct, PCIe 4.0 x16,
No Crypto, Thumbscrew (Pull Tab) Bracket
Intended Audience
This manual is intended for the installer and user of these cards. The manual assumes basic
familiarity with the Ethernet network and architecture specifications.
Technical Support
Customers who purchased NVIDIAproducts directly from NVIDIA are invited to contact usthrough
the following methods:
URL:https://www.nvidia.com> Support
E-mail:enterprisesupport@nvidia.com
Customers who purchased NVIDIA Global Support Services, please see your contract for details
regarding Technical Support.
Customers who purchased NVIDIA products through an NVIDIA-approved reseller should first seek
assistance through their reseller.
Related Documentation
NVIDIAOFED for
Linux User Manual
and Release Notes
User Manual describing OFED features, performance, band diagnostic, tools content,
and configuration. See NVIDIA OFED for Linux Documentation.
WinOF-2 for
WindowsUser
Manual and
Release Notes
User Manual describing WinOF-2 features, performance, Ethernet diagnostic, tools
content, and configuration. See WinOF-2 for Windows Documentation.
NVIDIAVMware for
Ethernet User
Manual and
Release Notes
User Manual describing the various components of theNVIDIA ConnectX® NATIVE ESXi
stack. See http://www.nvidia.comProducts > Software > Ethernet Drivers > VMware
Driver
NVIDIAFirmware
Utility (mlxup)
User Manual and
Release Notes
NVIDIAfirmware update and query utility used to update the firmware. Seehttp://
www.nvidia.com> Products > Software > Firmware Tools >mlxup Firmware Utility
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Nvidia ConnectX-6 Dx Specifications

General

Product Name	Nvidia ConnectX-6 Dx
Category	Adapter
Network Interface	Ethernet, InfiniBand
Port Speed	200Gb/s
Form Factor	Low Profile
PCIe Interface	PCIe 4.0 x16
Operating Temperature	0°C to 55°C
Product Type	Network Adapter
InfiniBand Support	Yes
RoHS Compliance	Yes
Virtualization Support	SR-IOV
Data Link Protocol	Ethernet, InfiniBand
Ports	2
Ethernet Standards	IEEE 802.3
Security Features	IPsec, TLS
