UG8000-00 November 2002
Page 1-20
NV6256 Specifications
Table 1-3 lists the specifications for the NV6256 Universal Digital Router.
Table 1-3. NV6256 FRAME SPECIFICATIONS
TYPE PARAMETER
Electrical
AC Power 90-130/180-250 VAC, 50/60Hz, Auto-ranging
Fuses Crosspoint Module - 7A, 125V (F) F1 Fast & 1A, Auto Reset.
I/O Modules - 1A, Auto Reset.
Controller Module - 3A, 125V (F) F1 Fast.
Power Supplies - 8.0A, 90-130V; 6.3A, 180-250V.
Connectors 8, IEC Filtered AC
Power Consumption 2640 Watts (maximum)
Regulatory UL Listed and CE Compliant
Mechanical
Module Slots 32 Input modules, 8 channels each.
16 Output modules, 8 channels each.
8 128x32 Crosspoint modules.
2 Controller modules (1 Primary, 1 Optional Secondary).
1 Output Monitor module (Optional).
Power Supply Slots 8 (4 Main, 4 Optional Redundant) in separate frame
Dimensions EIA Standard: Electronics Frame (24 RU High) 42.0” (1,066.8mm) H x 19.0”
(482.6mm) W x 19.0” (482.6mm) D;
EIA Standard: Power Supply Frame (5 RU High) 8.75” (222.2mm) H x 19.0”
(482.6mm) W x 19.0” (482.6mm) D
Weight (fully loaded) Electronics Frame: 262.5 lbs (119.2kg)
Power Supply Frame: 97.25 lbs (44.2kg)
Inputs/Outputs Input/Output specifications follow SMPTE standards for SDI (259M) and HD-SDI
(292M) signals, where applicable.
Cable Equalization Automatic, designed for Belden 1694A @1.5Gb/s (HD) or Belden 8281 at 270Mb/
s (SD)
Video Ref Input
Type Analog PAL and/or NTSC Color Black
Connectors 4 BNC (2 pairs), Loop-thru
Return Loss >30dB to 5MHz
Performance
Reclocking Yes
Input to Output Delay <10ns
Crosspoint Granularity 128x32
GSC Node Bus For Tektronix SMS7000 Control System
External Communications Port
Type RS-422 Serial Ports, usage determined by software
Connectors 6, 9-pin, D-type (2 Primary, 2 Secondary, 2 Diagnostic)
External Alarm Port 1 D-type, 9-pin connector
Environmental
Operating Temperature 0 to 40 degrees Centigrade, Ambient
Relative Humidity 0 to 90%, non-condensing
