POWER CORD WIRING
The power cord differs depending on your location. See the information below. Also note that the power
cords supplied with this equipment provide the only means of mains disconnection. The socket-outlet must
be installed near the equipment and must be easily accessible.
NORTH AMERICAN POWER SUPPLY CORDS
The North American power cords supplied with this equipment have a molded grounding plug (NEMA 5-
15P) at one end and molded grounding receptacle (IEC 320-C13) at the other end (see figure below).
Conductors are CEE color-coded: Light blue (neutral), Brown (line) and Green or Green/Yellow (ground).
Operation of this equipment at voltages exceeding 130 VAC will require power supply cords which comply
with NEMA configurations.
INTERNATIONAL POWER SUPPLY CORDS
The International power cords supplied with this equipment have a molded grounding receptacle (IEC 320-
C13) at one end and stripped conductors (50/5 mm) at the other end (see figure below). Conductors are
CEE color-coded: Light blue (neutral), Brown (line) and Green/Yellow (ground). Other IEC 320-C13 type
power supply cords can be used if they comply with the safety regulations of the country in which they are
installed.
FCC (USA) COMPLIANCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
Line
Neutral
Ground (Earth)
Green or Green
with Yellow Stri
e
Blue
Brown
Line
Neutral
Ground (Earth)
Green with
Yellow Stripe
Blue
Brown
