UG8000-00 November 2002
Page 4-5
Figure 4-2. Rear Fan Removal in NV6128 and NV6256
Figure 4-3. Front Fan Removal in NV6128 and NV6256
AIREXHAUST
KEEPCLEAR6"MIN
AIREXHAUST
KEEPCLEAR6"MIN
FANSERVICEACCESS
AIREXHAUST
KEEPC;EAR6"MIN
I/O
Cooling
Fan#1
I/O
Cooling
Fan#2
FANSERVICEACCESS
AIREXHAUST
KEEPC;EAR6"MIN
Loosen these screws and
lift the fan assembly up and out.
FAN FAN
4
Loosen these screws
and pull on the fan assembly to slide it out.
