NXP Semiconductors MPC5777C - Page 52

Board Interface Connector
MPC5777C EVB User Guide, Rev. 1
52 NXP Semiconductors
Daughter Card
Mother Board
mP Pin Name(516/416)
Connector Pin #
Connector Pin #
Evaluation Board
Port
RXDC
201
201
PD15
3.3V_SR_MB
200
200
3.3V_SR
3.3V_SR_MB
199
199
3.3V_SR
3.3V_SR_MB
198
198
3.3V_SR
3.3V_SR_MB
197
197
3.3V_SR
x
196
196
PF0
x
195
195
PF1
x
194
194
PF2
x
193
193
PF3
x
192
192
PF4
x
191
191
PF5
x
190
190
PF6
x
189
189
PF7
x
188
188
PF8
x
187
187
PF9
x
186
186
PF10
x
185
185
PF11
x
184
184
PF12
TP8/TP10
183
183
PF13
x
182
182
PF14
x
181
181
PF15
1.25V_SR_MB
180
180
1.25V_SR
1.25V_SR_MB
179
179
1.25V_SR
1.25V_SR_MB
178
178
1.25V_SR
1.25V_SR_MB
177
177
1.25V_SR
x
176
176
PH0
x
175
175
PH1
x
174
174
PH2
x
173
173
PH3
x
172
172
PH4
x
171
171
PH5
x
170
170
PH6
x
169
169
PH7
x
168
168
PH8
x
167
167
PH9
x
166
166
PH10
x
165
165
PH11
x
164
164
PH12
x
163
163
PH13
x
162
162
PH14
x
161
161
PH15
