Board Interface Connector
MPC5777C EVB User Guide, Rev. 1
53 NXP Semiconductors
Daughter Card
Mother Board
mP Pin Name(516/416)
Connector Pin #
Connector Pin #
Evaluation Board
Port
3.3V_SR_MB
160
160
3.3V_SR
3.3V_SR_MB
159
159
3.3V_SR
3.3V_SR_MB
158
158
3.3V_SR
3.3V_SR_MB
157
157
3.3V_SR
x
156
156
PJ0
x
155
155
PJ1
x
154
154
PJ2
x
153
153
PJ3
x
152
152
PJ4
TP6
151
151
PJ5
x
150
150
PJ6
TP9/TP8
149
149
PJ7
x
148
148
PJ8
x
147
147
PJ9
x
146
146
PJ10
x
145
145
PJ11
x
144
144
PJ12
x
143
143
PJ13
x
142
142
PJ14
x
141
141
PJ15
x
140
140
x
x
139
139
x
x
138
138
x
x
137
137
x
x
136
136
PL0
x
135
135
PL1
x
134
134
Pl2
x
133
133
PL3
x
132
132
PL4
x
131
131
PL5
x
130
130
PL6
x
129
129
PL7
x
128
128
PL8
TP7
127
127
PL9
x
126
126
PL10
TP3
125
125
PL11
x
124
124
PL12
TP4
123
123
PL13
x
122
122
PL14
TP5
121
121
PL15
