Ochsner Air Eagle 717 - Conduit to House

BA_OCHSNER AIR EAGLE_414_717_V06_EN.docx Page 31 of 76
Figure 42: Max. height difference
Figure 43: Oil lift bends
A
Liquid line
B
Hot gas line (thicker copper pipe)
C
Oil lift bend in the hot gas line (min. bending radius 5x diameter)
5.2 Conduit to house
Figure 44: Conduit to house (dimensions in mm)
max. 15 m
A
C
max. 15 m
B
5 m
5 m
Drainage
gravel bed
Drainage pipe
