13.2 Data table (T200 indoor unit)
APPLIANCE DATA:
Height
mm
1931
Width
mm
680
Depth
mm
855
Tilt height
mm
2121
Empty weight
kg
203
Filled weight
kg
471
IP rating
IP 20
Tank thermal insulation
mm
90
Heat exchanger area
m²
3.3
Heat exchanger capacity
l
21
DHW TANK:
Nominal capacity
l
168
Material
Enamelled steel
Energy efficiency class
C
Standby losses
W
65
Tank volume
l
189
Standby power consumption at 65°C
kWh/24h
1.6
Standby power consumption at 65°C
W
79
Area of smooth tube coil
m²
3.2
Max. operating pressure
bar
10
Test pressure
bar
15
Draw-off rate of DHW tank
l/min
25
BUFFER TANK:
Nominal capacity
l
100
Material
Steel
Max. operating pressure
bar
3
Test pressure
bar
4.5
Max. permissible temperature
°C
95
Water hardness
°dH
≤3
pH value (with aluminium compounds)
8.0-8.5
pH value (without aluminium compounds)
8.0-10.0
Conductivity (softening)
µS/cm
<1000
Conductivity (desalinated)
µS/cm
20-100
Chloride
mg/l
<30
Oxygen 8-12 weeks after filling (softening)
mg/l
<0.02
Oxygen 8-12 weeks after filling (desalination)
mg/l
<0.1
Max. power consumption of charging pump
W
72
Max. power consumption of heating circuit pump
W
72
CONNECTION:
Connections on the heating side
inch
1" union nut
Cold water connection
inch
1" union nut
DHW connection
inch
1" union nut
DHW circulation connection
mm
12
Table 8: T200 Specification
