Ochsner Air Eagle 717 - 13 Specification; Data Table (with Golf-MIDI Indoor Unit)

BA_OCHSNER AIR EAGLE_414_717_V06_EN.docx Page 56 of 76
13 Specification
13.1 Data table (with Golf-Midi indoor unit)
APPLIANCE DATA:
EAGLE 717
EAGLE 414
Dimensions of outdoor unit HxWxD
[mm]
1260 x 1480 x 960
Dimensions of indoor unit HxWxD
[mm]
1150 x 400 x 650
Hydraulic connection
[inch]
1" fem.
Weight of outdoor unit
[kg]
200
Weight of indoor unit
[kg]
70
Casing colour
outdoor
RAL 7016, anthracite grey
HEATING MODE PERFORMANCE FIGURES:
EAGLE 717
EAGLE 414
Standard point A7/W35
Heating output range
[kW]
6.7 - 8.3
3.5 - 10.6
Total heating output / power consumption EN 14511
[kW]
7.1 / 1.5
6.0 / 1.3
COP EN 14511
4.8
4.5
Standard point A2/W35
Heating output range
[kW]
6.0 - 10.4
3.1 - 10.2
Total heating output / power consumption EN 14511
[kW]
7.1 / 1.7
5.5 / 1.4
COP EN 14511
4.2
4
Standard point A7/W55
Heating output range
[kW]
6.6 - 8.6
3.9 - 11.0
Total heating output / power consumption EN 14511
[kW]
8.6 / 2.7
6.4 / 2.1
COP EN 14511
3.3
3.1
Standard point A-7/W34
Heating output range
[kW]
5.2 - 14.1
2.6 - 8.6
Total heating output / power consumption EN 14825
[kW]
12.8 / 4.1
7.8 / 2.7
COP EN 14825
3.1
2.9
SPECIFICATION:
EAGLE 717
EAGLE 414
Outdoor unit, controller (phases/nominal voltage/frequency)
[~]/[V]/[Hz]
3/400/50
1/230/50
Fuse protection (tripping curve "C")
[A]
16
20
Max. operating current
[A]
16
20
Max. starting current, compressor
[A]
< 10
< 10
Sound power level/sound pressure level at 3 m indoor unit
[dBA]
< 50/32
< 50/32
Electric auxiliary heater:
EAGLE 717
EAGLE 414
Phases/nominal voltage/frequency
[~]/[V]/[Hz]
3/400/50
1/230/50
3/400/50
Max. output
[kW]
8.8
8.8
8.8
Max. operating current
[A]
16
40
16
COOLING MODE:
EAGLE 717
EAGLE 414
Limits of use (outdoor temperature)
[°C]
15 - 40
15 - 40
Table 6: Specification (part 1)
