BA_OCHSNER AIR EAGLE_414_717_V06_EN.docx Page 57 of 76
CONDENSER:
EAGLE 717
EAGLE 414
Type
Plate heat exchanger
Material
Stainless steel 1.4301
Number
[pce]
1
1
Max. refrigerant operating pressure
[bar]
45
45
Max. heat transfer medium operating pressure
[bar]
3
3
Heat transfer medium temperature differential
[K]
5
5
Application range
[°C]
65
65
Heat transfer medium
Water
Water
Heat exchanger test pressure
[bar]
78
78
Heat transfer medium flow rate
[m³/h]
1.8
1.4
Internal pressure differential
[mbar]
220
160
Flow meter FM standard
internal
Circulation pump heat sink WNA
internal
Residual head I WNA external, incl. FM
[mbar]
380
590
REFRIGERANT CIRCUIT
EAGLE 717
EAGLE 414
No. of refrigerant circuits
[pce]
1
1
Refrigerant
R410A
R410A
Defrost technology
Hot gas
Hot gas
Refrigerant charge (from-to)
[kg]
5.5 - 7.3
8 - 9.2
COMPRESSOR:
EAGLE 717
EAGLE 414
Type
Scroll
Scroll
Number
[pce]
1
1
Output levels
Infinitely variable
Infinitely variable
Speed
[rpm]
2100-7000
2100-7000
Voltage/frequency
[V]/[Hz]
400/50
230/50
FAN:
EAGLE 717
EAGLE 414
Type
axial
Number
[pce]
1
Voltage/frequency
[V]/[Hz]
230
Power consumption
[W]
230
EVAPORATOR:
EAGLE 717
EAGLE 414
Unit type
Type
Finned tube
Number
[pce]
1
Air flow rate
[m³/h]
4000
Sound pressure level at 10 m /Sound power level at standard
conditions A7/W55
[dBA]
29/57
Table 7: Specification (part 2)
