BA_OCHSNER AIR EAGLE_414_717_V06_EN.docx Page 5 of 76
2 Appliance description
2.1 Heat pump
OCHSNER AIR EAGLE 717 and OCHSNER AIR
EAGLE 414 are air/water heat pumps configured
as split appliances.
The appliance extracts heat at a low temperature
from the outdoor air and releases it to the heating
water at a higher temperature. Heating water can
be heated to a flow temperature of up to 65°C.
The appliance is equipped with an electric
booster heater (DHC). In monovalent mode, the
electric booster heater is switched on when the
bivalent point is not reached to ensure heating
mode or the provision of high DHW
temperatures.
Special features of this heat pump:
• Output-dependent refrigerant circuit
• Variable speed compressor
• Refrigerant circuit controller
• OTE heat manager
• Split outdoor unit with compressor
Additional properties:
•
Suitable for underfloor and radiator
heating systems
•
Low temperature heating systems are
preferred
•
Heat can still be extracted from the
outdoor air at temperatures as low as -
20°C
•
Corrosion protected - external cladding
components are made of powder coated
stainless steel
•
Includes all components and safety-
relevant devices required for operation
•
Contains non-flammable safety
refrigerant
Two different indoor units are available for the
air/water heat pump:
•
Golf-Midi indoor unit
•
T200 (MULTI TOWER) indoor unit
2.2 CE designation
The product you have purchased conforms to the
technical regulations valid at the time and is
compliant with CE standards.
2.3 Scope of delivery
The OCHSNER AIR EAGLE heat pump is delivered
in 2 sections.
Golf-Midi indoor unit:
The indoor unit is delivered without its casing
installed. The casing sections are in a separate
package on the same pallet.
Contents of packages:
• Name plate
• Cowl for outdoor installation
• Front panel
• Rear panel
• Side panels, left/right
• OTE controller sensor set
• Operating manual
Optional accessories:
• OTE sensor set for buffer
T200 (MULTI TOWER) indoor unit:
The following components are packed inside the
MULTI TOWER, next to the two pumps:
• Outside temperature sensor
• Adjustable feet
• Drain hose
• Operating manual
Gaskets for the hydraulic connection (heating
circuit flow/return, cold water, DHW) are
attached directly at the connections.
Outdoor unit:
The outdoor unit is shipped fully assembled. It is
transported on a pallet.
