Connections
Figure 14: View from above
Choosing the installation location
4.1.3.1 Minimum wall clearances
Figure 15: Minimum wall clearances
Room
temperature
<30°C
Controller voltage
230 V~
Booster heater
400 VAC
Sensors <12 V
Liquid line
DHW heating
return
Heating
return
DHW heating
flow
Heating
flow
Hot gas line
Pressure gauge
b
a
bar
40 cm
min 40 cm
min 40 cm
min 100 cm
65 cm
min 5 cm
