Oki B4100 Maintenance Manual

Code
Category
Status Message
Display Content
Remedy
42156801TH Rev.2 48 /
Oki Data CONFIDENTIAL
Table 5-1
Warming-up status
Online (ready) status
Power save status
The toner amount of the toner cartridge is small.
The toner sensor is faulty.
Life of I/D drum
The paper is in the manual feed mode.
Printing in progress
Ejection in progress
Request the paper to be set in the manual feed
mode.
The paper sizes are as follows:
Executive, Letter, Legal 14, Legal 13, A4, A5, A6,
B5, Monarch, DL, C5, COM-10, COM-9
xx: Paper size in the tray being selected
Normal status
Normal operation
Normal operation
Normal operation
Normal operation
Replace the toner sensor.
Change the I/D Unit and reset Drum counter see Section 3.1.1 (1)
Normal operation
Normal operation
Normal operation
Set the requested paper in the manual feed mode.
Warming Up
Online (Ready)
Power Save Mode
Toner Low
Toner Sensor
Change Drum
Manual Paper In
Printing In Progress
Ejection In Progress
Manual Request
Executive
Letter
Legal 14
Legal 13
A6
A5
A4
B5
Monarch
COM-10
DL
C5
COM-9
X=0, Non Warning
X=1, Toner Low
X=2, 3 Change Drum
X=0, Non Warning
X=1, Toner Low
X=2, 3 Change Drum
10003
10001
10094
10006
10093
40093
10097
10098
10099
411xx

Oki B4100 Specifications

Performance

print speed	19 pages per minute
CPU	200 MHz
time to first page	6.0 seconds
print resolution	1200 x 600 dpi
duty cycle	15, 000 pages per month

Memory

standard RAM	8 MB
maximum RAM	8 MB

Paper Handling

standard paper input	250-sheet Letter/Legal/Universal tray
paper size minimum	3.4" x 5.5"
paper size maximum	8.5" x 14"

Weight and Dimensions

size (WxDxH)	14" x 15.6" x 7.9"
size (WxDxH in cm)	35.5 cm x 39.5 cm x 20 cm
weight	22 lb. (10.0 kg)
