7. Troubleshooting and repair procedure
If a printer detects an un-recoverable error, the following service call error is displayed on
the LCD.
Service call
nnn: error
Note!
nnn indicates an error code.
When
a service call is displayed, the error code and the associated error information are
displayed in the lower row of the LCD display at the same time.
Be sure to take note of this error information (numerals indicating address and others)
and inform it to the related departments because the information is used for trouble
analysis and solution. Meaning of error codes and remedial measures are shown in
Tables 7-1-1 and 7-1-2.
Table 7-1-1 Operator alarm
Display on operator panel
ON
LINE
lamp
Inspection
lamp
Contents Code nnn
Change Paper in %TRAY%
%MEDIA_SIZE%
%MEDIA_TYPE%
Press ONLINE Button
Please see HELP for details
Off Blink Indicates unmatch between the
media type in the tray and the print
data occurs.
Prompt user to insert paper in the
tray.
Error 661 : Tray1
Error 662 : Tray2
Error 663 : Tray3
Unit of paper size in the Custom
mode follows the unit specified
display unit (menu setting) of the MP
tray unless otherwise specified by
driver.
If unit of paper size is specified by
driver, it is displayed in units specified
by driver.
Paper size in the Custom mode is
indicated as follows:
"<Width> x <Length> <unit>"
e
x :
210 x 297 mm
8.5 x 11.0 inch
User is requested to change paper of
the tray and press the ON LINE key.
Error
661
662
663
Display on operator panel
ON
LINE
lamp
Inspection
lamp
Contents Code nnn
Change Paper in MPTray
%MEDIA_SIZE%
%MEDIA_TYPE%
Press ONLINE Button
Please see HELP for details
Off Blink Indicates unmatch between the media
type in the tray and the print data
occurs. Prompt user to insert paper in
the tray.
Error 660: MP Tray
Unit of paper size in the Custom
mode follows the unit specified
display unit (menu setting) of the MP
tray unless otherwise specified by
driver. If unit of paper size is specified
by driver, it is displayed in units
specified by driver.
ex: 210 x 297mm
8.5 x 11.0 inch
User is requested to change paper of
the tray and press the ON LINE key.
Error
660
Change Paper in %TRAY%
%MEDIA_SIZE%
%MEDIA_TYPE%
Press ONLINE Button
Please see HELP for details
Off Blink Indicates that the paper size of the
tray or the paper size, and the media
type do not match the print data.
Prompt user to insert paper in the
tray.
Error 461: Tray 1
Error 462: Tray 2
Error 462: Tray 3
Unit of paper size in the Custom
mode follows the unit specified
display unit (menu setting) of the MP
tray unless otherwise specified by
driver. If unit of paper size is specified
by driver, it is displayed in units
specified by driver.
e
x: 210 x 297mm
8.5 x 11.0 inch
User is requested to change paper of
the tray and press the ON LINE key.
Error
461
462
463

Oki C610N Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	8 s
Time to first page (color, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Print speed (color, normal quality, A4/US Letter)	34 ppm
Maximum internal memory	768 MB
Mobile printing technologies	-
Supported network protocols (IPv4)	10/100-TX
Maximum duty cycle	75000 pages per month
Number of print cartridges	4
Total input capacity	300 sheets
Total output capacity	250 sheets
Multi-Purpose tray input capacity	100 sheets
Media weight (tray 1)	64-220gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 250 g/m²
Power requirements	220-240VAC, 50/60Hz
Compatible operating systems	Windows 2000 / XP Home / XP Professional / XP Professionalx64 / Server 2003 / Server 2003 for x64 / Server 2008 / Server 2008 x64 / Vista (32-bit) / Vista (64-bit); Mac OS X 10.3.9 - 10.6.1
Bundled software	Color Correct, OKI LPR, PrintSuperVision.net, Swatch Utility, Template Manager, Web Driver Installer, Print Control Server2, Print Control Client, Storage Device Manager, Gamma Utility, Profile Assistant, Colour Access Policy Manager
Power consumption (printing)	600 W
Power consumption (PowerSave)	15 W
Storage temperature (T-T)	-10 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Standard interfaces	Ethernet, USB 2.0
Product color	Black, White
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	546 mm
Width	435 mm
Height	340 mm
