7. Troubleshooting and repair procedure
7.5.3.(2) Stain on white print (Refer to Figure 7-2B.)
(2-1) Stain on white print (Partial stain)
Check item Check work
Action to be taken
at NG
(2-1-1) ID unit
Exposure of drum to
light
Is the drum left in a circumstance in which drum
surface is exposed to direct light for a long time?
Replace the ID
unit.
If any attempt
of using new ID
unit as a trial
is going to be
made, be sure to
use the System
Maintenance
Menu FUSE
KEEP MODE.
Leakage of toner Does toner leak out from either ID unit or from
toner cartridge?
Replace the ID
unit or toner
cartridge.
If any attempt
of using new ID
unit as a trial
is going to be
made, be sure to
use the System
Maintenance
Menu FUSE
KEEP MODE.
(2-1-2) Fuser unit
Offset toner of the
fuser unit
Check if the offset toner of the previous printing
is left adhered on the fuser unit or not, by visual
inspection.
Repeat blind
printing using
unwanted media
until offset toner
is created on print
media. Alternately
replace the
fuser unit. If any
attempt of using
new fuser unit as
a trial is going to
be made, be sure
to use the System
Maintenance
Menu FUSE
KEEP MODE.
(2-2) Stain on white print (overall stain)
Check item Check work
Action to be taken
at NG
(2-2-1) Print media
Type of print media Check to see that the print media which is used
f
or printing is not a specially thin media.
Use the normal
paper.
(2-2-2) High voltage terminal
ID unit terminal Check that the high voltage terminal of the ID
unit is contacting with the Contact Assembly
normally by visual inspection. (Refer to Figure
7-3.)
Replace the ID
unit or correct
the high voltage
terminal.
If any attempt
of using new ID
unit as a trial
is going to be
made, be sure to
use the System
Maintenance
Menu FUSE
KEEP MODE.

Oki C610N Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	8 s
Time to first page (color, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Print speed (color, normal quality, A4/US Letter)	34 ppm
Maximum internal memory	768 MB
Mobile printing technologies	-
Supported network protocols (IPv4)	10/100-TX
Maximum duty cycle	75000 pages per month
Number of print cartridges	4
Total input capacity	300 sheets
Total output capacity	250 sheets
Multi-Purpose tray input capacity	100 sheets
Media weight (tray 1)	64-220gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 250 g/m²
Power requirements	220-240VAC, 50/60Hz
Compatible operating systems	Windows 2000 / XP Home / XP Professional / XP Professionalx64 / Server 2003 / Server 2003 for x64 / Server 2008 / Server 2008 x64 / Vista (32-bit) / Vista (64-bit); Mac OS X 10.3.9 - 10.6.1
Bundled software	Color Correct, OKI LPR, PrintSuperVision.net, Swatch Utility, Template Manager, Web Driver Installer, Print Control Server2, Print Control Client, Storage Device Manager, Gamma Utility, Profile Assistant, Colour Access Policy Manager
Power consumption (printing)	600 W
Power consumption (PowerSave)	15 W
Storage temperature (T-T)	-10 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Standard interfaces	Ethernet, USB 2.0
Product color	Black, White
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	546 mm
Width	435 mm
Height	340 mm
