7. Troubleshooting and repair procedure
Check item Check work
Action to be taken
at NG
(1-1-5) LSI operation check
I/F signal supplied
from the CU/PU
board to the
Operator Panel
board.
Check if the signal is output to the OPE
connector
of the CU/PU board or not.
Pin-2: Send data (Sending data from the CU/PU
board)
Pin-5: CLR
If it is normal, the signal is output always.
Replace the
CU/PU board.
I/F signal supplied
from the CU/PU
board to the
Operator Panel
board.
Chec
k if the signal is output to the OPE
connector
of the CU/PU board or not.
Pin-3: Send data (Sending data from the CU/PU
board)
If it is normal, the signal is output always.
Replace the
Operator Panel
board.
(1-2) PLEASE WAIT
(If the message is left attended, the error number changes to "COMMUNICATION ERROR".)
Check item Check work
Action to be taken
at NG
(1-2-3) Implement version upgrade of the PU firmware
Version upgrade of
the PU firmware
When the PU firmware version upgrade is
completed, this display appears.
Check the PU firmware version number by using
the menu print or the maintenance function.
If the message
reappears after
the power is re-
started again,
implement the
confirmations of
sections (1-3-1).
(1-3) Error messages related to Operator Panel are displayed.
Check item Check work
Action to be taken
at NG
(1-3-1) Error message
Error message Check the error contents by referring to the Error
Message List.
Follow the
instruction.
(1-4) "RAM check in progress" or "Initializing" display is kept appearing.
Check item Check work
Action to be taken
at NG
(1-4-1) Operator Panel display freezes.
Operator Panel
display
"RAM check in progress" or "Initializing" display
is kept appearing.
Replace the
ROM DIMM of
CU, or replace
the CU/PU
board.
Remove the
optional RAM
and SD Memory
card. Then
perform the
check.
If the check
result shows
NG, replace the
CU/PU board.

Oki C610N Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 1200 DPI
Time to first page (black, normal)	8 s
Time to first page (color, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Print speed (color, normal quality, A4/US Letter)	34 ppm
Maximum internal memory	768 MB
Mobile printing technologies	-
Supported network protocols (IPv4)	10/100-TX
Maximum duty cycle	75000 pages per month
Number of print cartridges	4
Total input capacity	300 sheets
Total output capacity	250 sheets
Multi-Purpose tray input capacity	100 sheets
Media weight (tray 1)	64-220gsm
Paper tray media types	Plain paper
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	64 - 250 g/m²
Power requirements	220-240VAC, 50/60Hz
Compatible operating systems	Windows 2000 / XP Home / XP Professional / XP Professionalx64 / Server 2003 / Server 2003 for x64 / Server 2008 / Server 2008 x64 / Vista (32-bit) / Vista (64-bit); Mac OS X 10.3.9 - 10.6.1
Bundled software	Color Correct, OKI LPR, PrintSuperVision.net, Swatch Utility, Template Manager, Web Driver Installer, Print Control Server2, Print Control Client, Storage Device Manager, Gamma Utility, Profile Assistant, Colour Access Policy Manager
Power consumption (printing)	600 W
Power consumption (PowerSave)	15 W
Storage temperature (T-T)	-10 - 43 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
Standard interfaces	Ethernet, USB 2.0
Product color	Black, White
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	546 mm
Width	435 mm
Height	340 mm
