5. Maintenance Menu

Table 5-3 SWITCH SCAN details

<Item having no function> Asterisk mark (*)

is displayed in the lower row of display area.

* 1: “L” is displayed when the cover is opened.

Display area, upper row

1 2 3 4

Details

Display area,

lower row

Details

Display area,

lower row

Details

Display area,

lower row

Details

Display area,

lower row

PAPER ROUTE : PU Entrance sensor 1

H: No paper

L: Paper exists

Entrance sensor 2

H: No paper

L: Paper exists

Write sensor

H: No paper

L: Paper exists

Exit sensor

H: No paper

L: Paper exists

TONER SENS Toner sensor K

H: Light is interrupted

L: Reﬂected

Toner sensor Y

H: Light is interrupted

L: Reﬂected

Toner sensor M

H: Light is interrupted

L: Reﬂected

Toner sensor C

H: Light is interrupted

L: Reﬂected

CVO UP_LU_FU Cover open switch

H: Close

L: Open

ST_FD_FU JOBOFF

Stacker down

sensor

H: No paper

L: Paper exists

REG L/R_OHP_WG

Color registration

sensor L

AD value:

***H

Color registration

sensor R

AD value:

***H

HT THERMISTER

Fuser thermistor,

upper sensor

AD value:

***H

Fuser thermistor,

lower sensor

AD value:

***H

Fuser thermistor,

upper sensor, side

AD value:

***H

Heater frame

thermistor

AD value:

***H

HUM_TEMP_DEN Humidity sensor

AD value:

***H

Humidity sensor

AD value:

***H

Humidity sensor (k)

AD value:

***H

Humidity sensor

(YMC)

AD value:

***H

BELT_T Belt thermistor

AD value:

***H

ID UP/DOWN GREY GREY ID UpDown Sns

H: Down

L: Up

RFID COLOR*1 RFID antenna K

UID:

***H

RFID antenna Y

UID:

***H

RFID antenna M

UID:

***H

RFID antenna C

UID:

***H

T1 PE_PNE_CVO

Tray 1 paper end

sensor

H: No paper

L: Paper exists

T1 CASETTE SIZE*1 Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L

T2 PE_PNE_CVO_CA

Tray 2 paper end

sensor

H: No paper

L: Paper exists

T2 HOP_LF_FED 2nd-Hopping Sns

H: No paper

L: Paper exists

Tray 2 entrance

sensor

H: No paper

L: Paper exists

T2 CASETTE SIZE*1 Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L

T3 PE_PNE_CVO

Tray 3 paper end

sensor

H: No paper

L: Paper exists

T3 HOP_LF_FED 3rd-Hopping Sns

H: No paper

L: Paper exists

Tray 3 entrance

sensor

H: No paper

L: Paper exists

T3 CASETTE SIZE Size setting switch 1 Port level H, L Size setting switch 2 Port level H, L Size setting switch 3 Port level H, L Size setting switch 4 Port level H, L

DUP IN_RA_FNT

Duplex (2-sided

printing) entrance

sensor

H: No paper

L: Paper exists

Duplex (2-sided

printing) front

sensor

H: No paper

L: Paper exists

DUP SK_CVO

Duplex (2-sided

printing) bottom

sensor

H: No paper

L: Paper exists

Duplex (2-sided

printing) cover

sensor

H: Close

L: Open
