5. MAINTENANCE MENUS
5.3.2.8 Consumable counter display
The consumable counter display is used for viewing the usage of consumables.
1. Enter the self-diagnostic mode and, until CONSUMABLE STATUS appears, press
the MENU up-arrow (
) or MENU down-arrow ( ) button (the MENU up-arrow ( )
button displays the next test option and the MENU down-arrow ( ) button displays
the preceding test option). Then press the ENTER button.
2. Pressing the MENU up-arrow (
) or MENU down-arrow ( ) button displays the
usage of each consumable (pressing the ONLINE or CANCEL button is disabled).
3. Press the BACK button to end the option (the state in step 1 is restored).
Upper display Lower display
Display
format
Display
unit
Detail
K-ID UNIT ********IMAGES Decimal Images Each displays the number of
turns performed by an image
drum unit in three-pages-per-job
printing to date after the first-time
installation of it, converted on an
A4 page basis.
Y-ID UNIT ********IMAGES Decimal Images
M-ID UNIT ********IMAGES Decimal Images
C-ID UNIT ********IMAGES Decimal Images
FUSER UNIT ********PRINTS Decimal Prints Displays the number of prints
made to date after the first-time
installation of a fuser unit.
TR BELT UNIT ********IMAGES Decimal Images Displays the number of prints
made to date after the first-time
installation of a belt unit.
K-TONER
(FULL)
********% Decimal % Each displays the usage of toner
of a color.
Y-T
ONER
(FULL)
********% Decimal %
M-TONER
(FULL)
********% Decimal %
C-TONER
(FULL)
********% Decimal %
Upper display Lower display
Display
format
Display
unit
Detail
M-WASTE
TNR CNT
********TIMES Decimal Times Each displays the amount of
waste toner. * 32 times or more
indicates the printer is full of
waste toner.
C-WASTE
TNR CNT
********TIMES Decimal Times
K-STC MODE
CNT
********TIMES Decimal Times Each displays the print dot count
of toner of a color (life counter
value after the printer goes into
operation).
Y-STC MODE
CNT
********TIMES Decimal Times
M-STC MODE
CNT
********TIMES Decimal Times
C-STC MODE
CNT
********TIMES Decimal Times
K OV
ER RIDE
CNT
********TIMES Decimal Times Each displays the extension
life counter value of a toner
cartridge.
Y
OVER RIDE
CNT
********TIMES Decimal Times
M OV
ER RIDE
CNT
********TIMES Decimal Times
C OV
ER RIDE
CNT
********TIMES Decimal Times
