Oki C810 - Gear Box, Registration;Hopping Roller Assy. and Solenoid

44015503TH Rev. 1
89 /
Oki Data CONFIDENTIAL
4. REPLACEMENT OF PARTS
4.2.18 Gear box, registration/hopping roller Assy. and
solenoid
(1) Remove the registration roller Assy. (see section 4.2.17).
(2) Unclamp the cable
from the solenoid and remove the screw (silver-colored)
to detach the solenoid.
(3) Remove the screw
.
