Oki C830 - Page 116

44015503TH Rev. 1
115 /
Oki Data CONFIDENTIAL
4. REPLACEMENT OF PARTS
Sensor-registration-Assy.
Cassette-Assy.
Class-C Molykote (EM-30L)
to posts (3 places)
Fuser-shutter
Class-C EM-30L to rotational support points and sides
Frame-separation-Assy.
1
2
Areas free of grease
Roller-Assy.-idler (FD)
Grease Application:
Apply a very small amount (Class S) of Molykote (EM-30L) to the sliding areas of
and (hatched areas) before assembling them.
