- 55 -
Installing the Device
AppendixPrinting
3
Setting Up
2
Before use
1
Basic Device Operations
4
Index
7
Close the access cover.
8
Tighten the access cover screws.
9
Connect the cables, and turn ON the
device power supply.
10
Check that the standby screen is
displayed in the liquid crystal panel.
11
Print the "Conguration".
Press either the scroll button
or
on the control panel to display the
"Functions" screen.
Memo
Print the "Conguration" on A4 size paper. Set A4
size paper in the paper feed tray.
12
Press the scroll button to select [Print
Information], and then press the [OK]
button.
13
When the [Conguration] have been
selected, press the [OK] button.
14
When [Execute] has been selected,
press the [OK] button.
15
Check that the HDD has been added to
the "Conguration".
Reference
“Printer Information” (P.60)
To Next Page
