Operating instructions > 49
Cut Sheet
Top cont.
Page Length Select the page length of
cut sheet.
279.4 mm (11” in)
296.3 mm (11 2/3”)
304.8 mm (12”)
420.9 mm (16.57”)
355.6 mm (14”)
76.2 mm (3”)
82.6 mm (3.25”)
84.7 mm (10/3”)
88.9 mm (3.5”)
93.1 mm (11/3”)
101.6 mm (4”)
127.0 mm (5”)
139.7 mm (5.5”)
152.4 mm (6”)
177.8 mm (7”)
203.2 mm (8”)
215.9 mm (8.5”)
Initial Position
(Displayed when
connected to the
RPS)(ML5720/
ML5790)
Select the vertical print
position when printer is
turned on.
Print Position
Cut Position
Cut Position Adjust
(Displayed when
connected to the
RPS)(ML5720/
ML5790)
Select an adjustment
value for the position to
cut the end of a
continuous form.
-20 ~ -1
0
+1 ~ +20
-30 ~ -1
0
+1 ~ +30
Wait Time Select the waiting time
between setting paper
on the tray and feeding
it while the printer is
waiting for paper to be
fed in cut sheet manual
feed mode.
Invalid
0.5 sec
1.0 sec
1.5 sec
2.0 sec
3.0 sec
Paper Length
Control
Control the page length
of cut sheet.
by MENU setting
by Actual Page
Length
by MENU setting
by Actual Page
Length
Cut Sheet Auto
Eject Position
Select a printable area
at the bottom of cut
sheets of paper in cut-
paper mode (the
character center
position.)
6.35 mm (3/12”)
12.70 mm (6/12”)
14.82 mm (7/12”)
Invalid
TOF Adjust Select an adjustment
value for the reference
position in regard to the
TOF position of cut sheet
paper.
The position moves to
the rear of the form by
(+) and to the top of the
form by (-) in /1/144”
(ML5720/ML5721) and
1/180” (ML5790/
ML5791) increments.
-20 ~ -1
0
+1 ~ +20
-30 ~ -1
0
+1 ~ +30
GROUP ITEM FUNCTION SETS
ML5720/ML5721 ML5790/ML5791
