Oki ML5720 User Manual

Operating instructions > 50
Cut Sheet
Top cont.
Cut Sheet Top of
Form
Select the reference
position for the TOF
position when feeding
cut sheet. (Up to the
mid-section of
characters in the first
line.)
2.12 mm (1/12”)
4.23 mm (2/12”)
6.35 mm (3/12”)
8.47 mm (4/12”)
10.58 mm (5/12”)
12.70 mm (6/12”)
14.82 mm (7/12”)
16.93 mm (8/12”)
19.05 mm (9/12”)
21.17 mm (10/12”)
23.28 mm (11/12”)
25.40 mm (12/12”)
27.52 mm (13/12”)
User Top of Form
LF Revise Adjust a line feed in the
cut sheet mode.
-14 ~ -1
0
+1 ~ +14
Centering Position Select to limit printhead
travel when printing
narrow columns.
Select Mode1 for
ML5720.
Select Mode 1 or Mode 2
for ML5721.
Default
Mode 1
Mode 2
Cut Sheet
Front
Line Spacing Select line feed pitch. 6 LPI
8 LPI
Page width
(Displayed only for
ML5721/ML5791)
Change to 8” to print on
narrow paper.
345.44 mm (13.6”)
203.2 mm (8”)
Page Length Select the length of cut
sheet.
279.4 mm (11”)
296.3 mm (11 2/3”)
304.8 mm (12”)
355.6 mm (14”)
420.9 mm (16.57”)
76.2 mm (3”)
82.6 mm (3.25”)
84.7 mm (10/3”)
88.9 mm (3.5”)
93.1 mm (11/3”)
101.6 mm (4”)
127.0 mm (5”)
139.7 mm (5.5”)
152.4 mm (6”)
177.8 mm (7”)
203.2 mm (8”)
215.9 mm (8.5”)
Wait Time Select the waiting time
between setting paper
on the tray and feeding
it while the printer is
waiting for paper to be
fed in cut sheet manual
feed mode.
Invalid
0.5 sec
1.0 sec
1.5 sec
2.0 sec
3.0 sec
Paper Length
Control
Control the page length
of cut sheet.
by MENU setting
by Actual Page
Length
by MENU setting
by Actual Page
Length
GROUP ITEM FUNCTION SETS
ML5720/ML5721 ML5790/ML5791
