Operating instructions > 51
Cut Sheet
Front
cont.
Cut Sheet Auto
Eject Position
Select a printable area
at the bottom of cut
sheet paper in cut sheet
mode (the character
centre position).
6.35 mm (3/12”)
12.70 mm (6/12”)
14.82 mm (7/12”)
Invalid
TOF Adjust Select an adjustment
value for the reference
position in regard to the
TOF position of cut sheet
paper.
The position moves to
the rear of the form by
(+) and to the top of the
form by (-) in 1/144”
(ML5720/21) and 1/180”
(ML5790/91)
increments.
-20 ~ -1
0
+1 ~ +20
-30 ~ -1
0
+1 ~ +30
Cut Sheet Top of
Form
Select the reference
position for the TOF
position when feeding
cut sheet. (Up to the
mid-section of
characters in the first
line.)
2.12 mm (1/12”)
4.23 mm (2/12”)
6.35 mm (3/12”)
8.47 mm (4/12”)
10.58 mm (5/12”)
12.70 mm (6/12”)
14.82 mm (7/12”)
16.93 mm (8/12”)
19.05 mm (9/12”)
21.17 mm (10/12”)
23.28 mm (11/12”)
25.40 mm (12/12”)
27.52 mm (13/12”)
User Top of Form
LF Revise Adjust a line feed
amount in the cut sheet
mode.
-14 ~ -1
0
+1 ~ +14
Centering Position Select to limit printhead
travel when printing
narrow columns.
Select Mode1 for
ML5720/ML5790.
Select Mode 1 or Mode 2
for ML5721/ML5791.
Default
Mode 1
Mode 2
Set-up Graphics Select the printing
direction when double-
height print data exists
in a line.
Uni-directional
Bi-directional
7 or 8 Bits
Graphics
(Displayed only for
ML Emulation)
Select to change
graphics settings.
7
8
-
Receive Buffer
Size
Select size of the
received buffer.
When “1 Line” is
selected, the receive
buffer size is set to 2 k
bytes.
0 K
1 Line
32 K
64 K
128 K
GROUP ITEM FUNCTION SETS
ML5720/ML5721 ML5790/ML5791
