Oki ML690 - Setting Top of Form (TOF)

ML690/ML691 User’s Guide 29
Setting Top of Form (TOF):
Notes:
Adjusting the TOF can be done in cut sheet or
continuous forms mode.
If necessary, print the menu settings to
determine where the current TOF is set.
The default TOF is set at 11/12” (23.28 mm).
With paper loaded and the printer on and selected:
Align the paper with the rst print line position as
follows:
To set the TOF lower (the rst line of print on
the page moves down), press and hold down
the LOAD/EJECT and SEL keys at the same
time.
To set the TOF higher (the rst line of print on
the page moves up), press and hold down the
LOAD/EJECT and LF/FF keys at the same time.
The paper moves in increments of 1/180”.
When you have the TOF set where you want it,
press and hold SEL, then press LF/FF to save the
new setting.
Note: To reset the Top of Form to the factory default,
see “Resetting Top of Form to the Factory
Default” later in this chapter.
1.


2.
