Oki ML690 - Appendix C: Specifications; Print Method; Printhead; Interfaces

ML690/ML691 User’s Guide 96
Appendix C:
Specications
Note: Specications are subject to change without
notice.
Print Method
Impact dot matrix
Printhead
24 pins, 0.2 mm (0.008”) diameter, with thermal
protection
Interfaces
Standard: Bi-directional parallel, IEEE-1284
compliant, USB 2.0
Optional: RS-232C Serial
Receive Buffer Size
Maximum 128K
Printhead Life
400 million characters average in 10 cpi draft
mode at 25% duty and 35% page density
Reliability
Ribbon Life
ML690: approx. 8 million characters (Draft Mode)
ML691: approx. 13 million characters (Draft Mode)
Emulations (co-resident)
IBM Proprinter
Epson FX
Physical Specications
Note: Height dimensions do not include the acoustic
cover.
ML690
Size (WxDxH): 16.3 x 12.6 x 6.26”
(414 x 320 x 159 mm)
Weight: 16.4 lb. (7.5 kg)
ML691
Size (WxDxH): 22.36 x 12.6 x 6.26”
(568 x 320 x 159 mm)
Weight: 22 lb. (10 kg)


