44952001TH Rev.2
5-21
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
5.4.5 Test printing
The test printing is used for printing test patterns stored in the PU. The controller stores the
other patterns.
The test printing cannot be used to check print quality.
See chapter 7 for diagnosing problem print images.
1. Enter the self-diagnostic mode (level 1) and, until TEST PRINT appears on the
upper display, press [2] or [8] ([2] displays the next test option and [8] displays
the preceding option). Then press the [6] button.
2. A setting option applied only to test printing appears on the lower display. Press [2]
or [8]
until a target option appears ([2] displays the next option and [8] displays
the preceding option). Then press the [6] button. [Go to step 5 when the options
do not need to be set (left set to their defaults)].
3. The setting option and its setting appear on the upper and lower displays,
respectively. Pressing [2] displays the next setting and pressing [8] displays the
preceding setting (the setting last displayed is applied. Press [4] to accept the
setting and return to step 2. Repeat step 3 when necessary.
TEST PATTERN
1
Display Settings Function
PRINT EXECUTE –
Starts printing with the press of [6] button, and ends
printing with the press of the [#] button.
TEST PATTERN 0
0: Prints a blank page.
1 to 7: - See the next section (pattern printing) -
8 to 15: Each print a blank page.
TEST CASSETTE TRAY1
Selects a paper source.
TRAY2 is not displayed when the tray 2 is not
installed.
TRAY2
MPT
PAGE 0000
Sets the number of test copies to print.
COLOR ON
Selects color or monochrome printing.
* ON and OFF are provided for each color when the
setting ON is specified.
OFF
DUPLEX 2 PAGES STACK
Performs duplex printing using a two pages layout.
Selects turning off duplex printing.
Performs duplex printing using a one page stack
layout.
OFF
1PAGES STACK
• Adefaultisinashadedarea( ). Set settings are enabled only in this test mode (not
written into the EEPROM).
Note: PAGE: .............Moves its input digit with [2] or [8]. The setting for this option
is incremented by pressing the [
] button, and decremented
by pressing the [#] button. Note that, when left set, the setting
0000 endlessly prints pages.
COLOR: ..........When set to ON, with the press of the [6] button, displays the
information shown below.
Setting option for printing colors: Moves its input position with [2] or [8]. The
setting for each color is switched between ON and OFF by the
press of the [
] or [#] button. The panel display is restored to
the previous one by pressing [4].
COLOR
→
Y:ON M:ON
ON C:ON K:ON
To Next Page
