44952001TH Re
v
.2
4-5
Oki Data CONFIDENTIAL
4.REPLA
CEMENT OF P
AR
TS
4.2.2
Fuser unit
(1)
Open the
scanner and the top cover
.
(2)
Pull the (blue) fuser unit loc
k lev
er in the direction of the arr
ow and detach the fuser
unit
â‘
.
4.2.3
Left side cov
er
(1)
Open the
scanner and the top cover
.
(2)
Remove the two (silver-colored) screws
â‘
.
(3)
Unlatch and
detach the left
side cover
â‘¡
.
Fuser unit lock le
ve
r (blue)
Scanner
T
op co
ve
r
Fuser unit lock le
v
er (blue)
T
op co
ve
r
Scanner
93
95
