4.3.8 Job-Offset-Assy 723 and Basket-Assy
(1) Open the Cover Assy-Top.
(2) Unscrew screw
, remove Frame-Duct , then remove the connector (remove the
connector through the shaft)
(3) Remove the 2 hinges, then remove the Job-Offset-Assy
, and disconnect the con-
nector.
(4) Unscrew 2 screws
, then remove the 2 hinges, and remove the Cover Assy-Top (Sub)
.
(5) Remove the six screws
of the Guide-Link-R and the three screws of the Guide-
Link-L. Remove the Plate-Top and the Basket Assy with their interlock.
(6) Remove the 2 hinges, then remove the Cover Assy-Top (Sub)
.
(7) Remove the Side Cover (L) Rear
.
(8) Remove the E-ring
, unscrew 2 screws , then remove the Plate-Support (Top) ,
Collar , Shaft-Top (A) , Spring-Torsion-Top (L) , Spring-Torsion-Top (B) .
(9) Unscrew 3 screws
, then remove the Gear-Assy-L .
(10) Unscrew 3 screws
, then remove Gear-Assy-R .
(11) Remove the high toner Assy tube
, then remove Basket-Assy .
