Oki MPS9650c - Belt-Assy

Oki Data CONFIDENTIAL
43627911TH Rev. 3
128 /
4.3.18 Belt-Assy
(1) Open the Cover Assy-Top
.
(2) Remove ID Units
.
(3) Lift up the 2 lock levers toward the arrow, then remove the Belt-Assy
.
Remove Belt-Assy
by lifting handle , then remove along with handle .
