Oki Data CONFIDENTIAL
43627911TH Rev. 3
243 /
9.2 Illustration appears on the operating panel
When troubles occur, an illustration and message may appear on the operating panel.
See the following table for detail instruction.
Front view of printer Opening the top cover Side view (left) of printer Side view (right) of printer
Indicates a cyan toner
cartridge
Indicates a magenta toner
cartridge
Indicates a yellow toner
cartridge
Indicates a black toner
cartridge
Indicates a cyan image
drum
Indicates a magenta
image drum
Indicates a yellow image
drum
Indicates a black image
drum
Indicates a fixation unit Indicates a fixation unit Indicates a belt unit
Indicates a paper route
inside printer
Indicates a disposal toner
unit
Indicates a disposal toner
unit
To Next Page
