4.3.12 FDR Unit-MPT

(1) Open the Cover Assy-Top.

(2) Remove the Cover

and remove the two connectors (Pin and Pin 2).

(3) Open the FDR Unit-MPT

and remove the two screws fastening the stays on

both sides.

(4) Further open the FDR Unit-MPT

and remove the FDR Unit-MPT from the sup-

port in two places.

Oki MPS9650c Maintenance Manual
