2.14 Reading Version of Routine Replacement Units
This determines whether the parts are new or old according to the I/D of the consumable parts
that are routinely replaced, the fuser unit, and the state of the fuse in the belt unit (good/dead). If
the fuse is in a conductive state, then it is considered a new unit. A NEW or OLD decision takes
place when the power is turned ON and when the cover is closed. When the part is NEW, the
life counter of the unit is reset, and the NEW/OLD decision-making fuse in each unit is cut.
2.15 Life Counter of Replaceable Units
The following Table lists the life counter of the I/D, fuser unit, and belt unit that are routinely re-
placed consumable parts.
Unit State Life processing
ID Count the drum rotation in a unit of [Letter
Paper Length + Paper Interval during
continuous print].
Life :When printing a distance equivalent to
30K sheets (3P/J).
Stop Printing
However, 1500 sheets can be
printed by opening and closing the
cover.
Toner Cartridge Count the number of print dots.
Determine the usage level according to the
counter value.
(Refer to 2.16)
Stop Printing
However, 50 sheets can be printed
by re-turning the power back ON or
opening/closing the cover. (A4 5%)
Belt Unit Convert the drum rotation into [Letter Paper
Length + Distance Between Paper
Upon Continuous Printing].
One sheet of paper passing through is
counted as one on the counter.
Life:When the counter value reached 100K.
Stop Printing
However, 20 sheets can be printed
by re-turning the power back ON or
opening/ closing the cover.
Fuser Unit Disposal Toner Near-Full state.
If paper is longer than 13 inches, the number
of the paper sheets will be an integer
multiplied by 13 inches plus one.
Life: When counter value is 100K.
Stop Printing
However, power is turned off and
on again or opening/ closing the
cover, the printer will be able to
print 500 more sheets or, after
150K, 50 more sheets.
Waste Toner Box Converts the weight of discharged toner to
the number of A4 sheets and counts the
number.
Life: When the counter has reached 30K.
Stop Printing
When power is turned off and on
again or opening/closing the cover,
the printer will be able to print up to
50 counts.
2.16 Toner Usage Level Detection
The toner usage level is detected by counting the number of dots printed. The counted number
of dots is written in the IC chip in a toner cartridge.
Once toner low is detected, the toner shall be considered empty after dot counting 1,050 A4
sheets at 5%.
However, when the power is turned back ON, and the cover is opened and closed, the printer
can still print 50 more sheets.
