Oki Data CONFIDENTIAL
43627911TH Rev. 3
131 /
Latch
4.3.21 Paper Feed Roller
(1) Open the tray 1 side cover
and the paper guide .
(2) Pull out Tray
.
(3) Pull outward the latches of the 3 paper feed rollers
, and remove from the shaft.
