Oki Data CONFIDENTIAL
43627911TH Rev. 3
194 /
(a)
• YES Is the DIMM of the Main PCB set properly?
NO Set the DIMM properly. If that does not solve the problem, replace the
DIMM.
• YE
S Are the voltages below output to the PU IF connector of the Main PCB?
Pins 9, 10, 17, 18, 25, 26, 33, 34, 41, 42, 61, 69, 77, 85, 93: +5V±5%
Pins 1, 2, 5, 6, 13, 14, 21, 22, 29, 30, 37, 38, 45, 46, 47, 48, 49, 53, 57, 65, 73,
74, 81, 82, 89, 97, 99: 0V
YES Replace the Main PCB.
• NO Is +5V output the DENGEN connector of the Engine PCB?
Pins 1 & 3: +5V, Pins 2 & 4: 0V
YES Replace the Engine PCB.
• NO Replace the Low-Tension Power Supply Unit.
To Next Page
