STEP 4 - Gable End Midwall Brace - RM1
X13A
X13B
Note: Line up
the two end
holes
Note: The Gable End Midwall Brace 'RM1' have TWO ROUND HOLES AT
EACH END not four round holes as the Side Midwall Braces 'SM'.
Do not fix nuts and bolts in these holes.
Leave the two end holes of 'RM1' empty on both ends for fixing on step 13.
From the 'E' and 'B' Packs join together two pairs of Gable End Midwall Braces 'RM1's' to make
two Gable End Midwall Braces 'RM1'. Ensure when joining the pair together that the end round
holes are lined up at each end of the Back Midwall Braces as shown in the diagram.
Always place each of the joined Gable End Midwall Braces at opposite ends of the foundation
where the Gables are to be.
RM1 For
}
1x
10x15
10x19
12
P
P
