8
WALL PANEL LAYOUT
Note: Codes for sheds with 2m wall height may differ from codes with shed with a
1.78m wall height. eg K = 1.78m wall sheet as shown in 1015HDDA diagram
K2 = 2m wall sheet as shown in 1019HDDA2 diagram
As shown in the diagrams below the Double Hinged Doors can be placed on any
side of the shed where there is a 3 Wall Panel K/K2 space.
eg Under the Gables as shown in 1015HDDA diagram
On long side as shown in 1019HDDA2 diagram
DOOR
PORTAL FRAME
Du cadre de portique
K K K K K K K
K K K K
F
K
K
K
F
F
F
PORTAL FRAME
K
K
K
DOOR
MODELS: 1015HDDA (shown)
1015HDDA2
PORTAL FRAME
PORTAL FRAME
PORTAL FRAME
K2 K2 K2 K2 K2 K2 K2 K2 K2
F2
K2
K2
K2
F2
K2 K2 K2
F2
F2
DOOR
DOOR
K2
K2
K2
L62
L62
K2 K2 K2
L6
L6
MODELS: 1019HDDA
1019HDDA2 (shown)
