MAESTRO SMART 5
2 DESCRIPTION OF THE UNIT
2.1 Structure
No. DESCRIPTION
1 Upper grill
2 Body
3
Louver
4 Display
5 Remote control
6 On/Off button
No. DESCRIPTION
7 Evaporator group
8 Condenser assembly group
9 Control panel
10 Base
11 Compressor group
12 Evaporating fan
