3K5-2
1-3-41
U203
Checking DP operation
Description
Simulates the original conveying operation separately in the DP.
Purpose
To check the DP operation.
Method
1. Press the start key.
2. Place an original in the DP if running this simulation with paper.
3. Select the item to be operated.
4. Press the start key. The operation starts.
5. To stop continuous operation, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U243
Checking the operation of the DP motors
Description
Turns the motors or solenoids in the DP on.
Purpose
To check the operation of the DP motors and solenoids.
Method
1. Press the start key.
2. Select the item to be operated.
3. Press the start key. The operation starts.
4. To turn each motor off, press the stop key.
Completion
Press the stop key when operation stops. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description Setting range Initial setting
CCD ADP
(NON P)
Without paper, single-sided original
(continuous operation)
--
CCD ADP With paper, single-sided original - -
CCD RADP
(NON P)
Without paper, double-sided original
(continuous operation)
--
CCD RADP With paper, double-sided original - -
SPEED
Switching between normal reading (600 dpi)
and high-speed reading
0 (Normal)/
1 (High-speed)
0
Display Motor and solenoid Operation
DP FEED MOT Original feed motor (OFM) In operation
DP CON MOT Original conveying motor (OCM) In operation
DP REV MOT Original switchback motor (OSBM) In operation
DP RP SOL Switchback pressure solenoid (SBPSOL) On for 0.5 s
DP RJ SOL Switchback feedshift solenoid (SBFSSOL) On for 0.5 s
Y108671-9 Service Manual
