Printer features 1-9
Printable area (documents)
The tables that follow the drawing give the values in mm of the right printing margins (
D
) and
length of the line of print (
L
) in numbers of characters, for right-aligned documents inserted
from the bottom and those inserted from the top.
All the values are given with reference to the selected print pitch (
CPI
).
Right-aligned documents
CPI 12.5 16.66
L (CRT) 66 88
D (mm) 7.09 7.09
NOTE:
The D parameter can vary of: 0 mm / + 2 mm.
