1-4 Printer features
Technical characteristics (double roll)
Paper loading Fully automatic
Motor unit Independent
Step motor 35 EP for receipt (on left)
Step motor 35 EP for journal (on right)
Vertical resolution 1/144"
Default line feed 12/72" = 1/6"
Paper out sensors Microswitch for receipt paper almost out
Microswitch for journal paper almost out
Non-usable paper at end of roll from 50 cm to 150 cm
Paper roll characteristics (double roll)
70 mm rolls
Maximum diameter 85 mm
Minimum diameter for automatic loading 55 mm
Paper width 70 mm +/- 0.5 mm
Paper weight:
Single copy (receipt/journal)
Double chemical copy (receipt)
50-55 g/m
2
original 50-55 g/m
2
copy 50-55 g/m
2
Receipt upper margin:
with FF command
with cutter command
33 mm +/- 1 mm
SW settable
